Date: 1700
COMMERCIAL PUMPS, MOTORS, and FLOW DIVIDERS
K41
MADE FROM PARTS OR ALREADY ASSEMBLED
Commercial 15H, 25X, 37X, 30, 31, 50, 51, 75, 76, 315, 350, 365 Pumps and Motors
Below are examples of Commercial numbers: Please call for price and stock.
FOR REPAIR AND REPLACEMENT - CALL US
SINGLE UNIT
Commercial pumps and motors are available as single or multiple
assemblies. The full assembly code for the finished unit combines indi-
vidual codes for shaft end cover, port end cover, gear housing, and drive
shaft. It is preceded by the letter P or M for pump or motor - and by a
number to designate the series.
PUMP MODELS START WITH LETTER
P;
MOTOR MODELS START WITH LETTER
M
Here is an example:
P25X SINGLE PUMP
Example Only
Assembly Code P25X 342 BE IT20-25
Pump ............................. P
1. Shaft End Cover .............................. 342
Series ...........................25
2. Port End Cover ................................. BE
Model ............................. X
3. Gear Housing ..................................IT20
4. Drive Shaft ......................................... 25
M25X SINGLE MOTOR
Example Only
Assembly Code P25X 342 BE IT20-25
Motor .............................M
1. Shaft End Cover .............................. 942
Series ...........................25
2. Port End Cover ................................. BE
Model ............................. X
3. Gear Housing ..................................IT20
4. Drive Shaft ......................................... 25
MULTIPLE UNIT
Multiple units are coded in the same manner except that additional
designations for added sub-components must be included. Each section
added to the single assembly requires a proper code for a bearing carrier,
gear housing and connecting shaft. Here is an example of an assembly
code for a two-section 37X pump:
P37X MULTIPLE PUMP
Example Only
Assembly Code P37X 178 BY VZ20-7 B IL 15-1
Pump ............................. P
1. Shaft End Cover .............................. 178
Series ...........................37
2. Port End Cover ................................. BY
Model ............................. X
3. Gear Housing .................................VZ20
4. Drive Shaft ........................................... 7
5. Bearing Carrier ....................................B
6. Gear Housing .................................. IL15
7. Connection Shaft ................................. 1
COMMERCIAL PUMP & MOTOR SEAL KITS, SHAFT SEALS, BEARINGS, & WEAR PLATES
Date: 2500
Seal Kits
|
Shaft Seals Metal Clad
|
Wear Plates
Pumps One Section
|
Pumps
|
Two Required Per Section
Part
Our Sequence
Per
| Part
Our Sequence
Per
| Part
Our Sequence Per
Number
Series
Number
Each
| Number
Series
Number
Each
| Number
Series
Number
Each
391-1802-031
P15H
MM55858
$13.18 | 391-2883-048
P15H 975940
$4.92 | 391-2185-907 P15H
975820
$43.09
391-1802-129
P25X
MM55875
15.34 | 391-2883-055
P25X 975946
7.86 | 391-2185-912 P25X
975822
24.28
391-1802-016
P37X
MM55850
16.06 | 391-2883-052
P37X 975945
8.11 | 391-2185-909 P37X
975821
36.37
CSK-P20A
P20A
EE3040
8.05 | 391-2883-058
P20A 975947
2.53 | 391-2185-913 P20A
975823
41.06
CSK-P20C
P20C
EE3050
18.97 | 391-2883-107
P20C 975957
11.77 | 391-2185-913 P20C
975823
41.06
391-1802-119
P30/31 MM55870
8.42 | 391-2883-058 P30/31 975947
2.53 | 391-2185-913 P30/31 975823
41.06
CSK-P30C/P31C P30/31 EE3060
19.34 | 391-2883-107 P30/31 975957
11.77 | 391-2185-913 P30/31 975823
41.06
391-1802-137
P50/51 MM55881
13.81 | 391-2883-103 P50/51 975955
6.98 | 391-2185-912 P50/51 975822
24.28
CSK-P50C/P51C P50/51 EE3080
14.62 | 391-2883-133 P50/51 975966
7.46 | 391-2185-912 P50/51 975822
24.28
391-1802-136
P75/76 MM55880
16.40 | 391-2883-052 P75/76 975945
8.11 | 391-2185-920 P75/76 975824
102.62
CSK-P315
P315
EE3065
14.63 | 391-2883-151
P315 975969
3.86 | 391-2185-963 P315
975830
53.89
391-1802-441
P330A
MM55941
14.39 | 391-2883-058
P330 975947
2.53 | 391-2185-956 P330
975828
58.19
CSK-P350
P350
EE3070
25.70 | 391-2883-103
P350 975955
6.98 | 391-2185-957 P350
975829
58.58
391-1802-494
P365
MM55945
24.55 | 391-2883-052
P365 975945
8.11 | 391-2185-955 P365
975827
57.49
391-1822-101
P5
97244064
27.74 | 391-2883-178
P5
9736693
9.07 |
P11-SK1VV
P11
9736649
76.11 | 391-2881-181
P11
9736699
2.32 |
8611-023-00N
PGP511 9717398
21.41 | 8301-019-00K PGP511 9717395
6.04 |
8611-023-Q1N
PGP511 9717397
22.52 | 9352-061-00T PGP511 9717394
4.83 |
391-1822-071
P17
97244060
51.97 | 391-2883-058
P17
975947
2.53 |
Date: 2500
Seal Kits Motors One Section
|
Shaft Seals Metal Clad Motors
|
Roller Bearings Four Required Per Section
|
|
391-1801-014
M15H
MM55813
7.20 | - - - - -
- -
.... | 391-0381-062 M15H
975757
23.14
391-1801-015
M25X-I MM55814
91.33 | 391-2883-096
M25X 975953
27.04 | 391-0381-059 M25X
975759
27.43
391-1801-009
M37X
MM55812
40.30 | 391-2883-094
M37X 975952
27.80 | 391-0381-060 M37X
975758
39.40
CSK-M20A
M20A
EE3000
26.15 | 391-2883-119
M20A 975962
17.85 | 391-0381-068 M20A
975760
12.70
CSK-M20C
M20C
EE3010
55.60 | 391-2883-126
M20C 975964
42.81 | 391-0381-068 M20C
975760
12.70
391-1801-032
M30/31 MM55822
26.52 | 391-2883-119 M30/31 975962
17.85 | 391-0381-068 M30/31 975760
12.70
CSK-M30C/M31C M30/31 EE3020
55.97 | 391-2883-126 M30/31 975964
42.81 | 391-0381-068 M30/31 975760
12.70
CSK-M50C
M50/51 EE3032
39.50 | 391-2883-186 M50/51 984056
27.93 | 391-0381-059 M50/51 975759
27.43
391-1801-063
M50/51 MM55842
46.96 | 391-2883-115 M50/51 975959
34.07 | 391-0381-059 M50/51 975759
27.43
391-1802-143
M75/76 MM55885
40.64 | 391-2883-094 M75/76 975952
27.80 | 391-0381-060 M75/76 975758
39.40
CSK-M315
M315
EE3029
70.23 |
|
391-0482-195 M315
975778
5.06
CSK-M330
M330
EE3030
69.08 | 391-2883-119
M330 975962
17.85 | 391-0482-306 M330
975779
13.19
CSK-M330C
M330
EE3031
166.61 | 391-2883-126
M330 975964
42.81 | 391-0482-306 M330
975779
13.19
391-1801-115
M350
EE3034
85.11 | 391-2883-115
M350 975959
34.07 | 391-0482-308 M350
975781
13.93
CSK-M350C
M350
EE3033
77.66 | 391-2883-186
M350 984056
27.93 | 391-0482-308 M350
975781
13.93
CSK-M365
M365
EE3035
109.13 | 391-2883-094
M365 975952
27.80 | 391-0482-307 M365
975780
19.91
391-1801-304
M5
9719695
51.93 |
Lip Seals Motor
391-1801-311
M11
9719705
124.88 | 391-2883-184
M5
9736645
14.27 335-0900-748 PGM511 97366486 13.02
8301-023-Q1N
PGM511 9717396
22.21 | - - - - -
- -
.... 9411-601-00N PGM511 9717393
12.75
M511-SKIVV/LG PGM511 97366493 42.06 | 391-2883-185Z hi M11
9736647
15.89 9411-601-00N PGM511 9736648
15.02
M511-SKIVV/MG PGM511 97366497 42.06 | 8301-020-00M PGM511 97366485 17.24
Prices subject to change without notice
