CONSTRUCTION SEAL KITS FOR CATERPILLAR® EQUIPMENT
Y11
Bore
Rod
Our Sequence
Per
Rod Piston
Rod
Application
S/N Range
Size
Diam. Kit Number
Number
Each
Wiper
Seal
Seal
Remarks
Boom
All
4.5
2.75
517255 AA1690 $75.38 MC 4-SWR SBR
Bucket
All
4.5
2.75
517254 AA1685
70.83 MC 4-SWR SBR
Stick
All
5.5
3.5
529253 AA2175
73.48 MC 4-SWR SBR
Track Adjuster
All
3.5
2.5
903404 AA2843
17.80 MC
VS
14Z1-UP
3.5
1.875
903400 AA28426
22.28 VS SWR SBR Use with 3V5278 Front Idler Group
Heavy Duty Arrangement
Boom
5CF1-730,
4.5
2.75
657375 AA2734
88.39 MC SWR SBRB 7X2683
2 Piece Boom
4HG1-2085
5CF1-730,
4.75 3.0
632376 AA2702 108.05 MC SWR SBRB
1 Piece Boom
4HG1-2085
5CF731-Up,
4.75 3.0
632376 AA2702 108.05 MC SWR SBRB Use w/ C 9T6417 head
9TF1-1185, 4HG2086-Up, 5XG
9TF1186-Up,5XG 4.75 3.0
632417 AA2704 120.65 MC SWR SBRB Use w/ C 6E3106 head
Bucket
5CF, 9TF1-1172
4.75 3.0
632376 AA2702 108.05 MC SWR SBRB
4HG, 5XF1-573
9TF1173-Up,
4.75 3.0
632418 AA2705 109.21 MC SWR SBRB
5XG574-Up
Stick
5.5
3.5
626253 AA2681 129.03 MC SWR SBRB 7X2726
Track Adjuster
9TF, 4HG
3.5
2.5
903404 AA2843
17.80 MC
VS
5CF, 5XG
3.5
1.875
903400 AA28426
22.28 VS SWR SBR
Boom
20S1-189,
5.5
3.25
525221 AA2000
63.74 MC SWR SBR
51U1-589, 76U1-693
20S190-Up,
5.5
3.25
525245 AA2015
71.15 MC 4-SWR SBR
51U1-589
51U590-2033,
5.5
3.25
525221 AA2000
63.74 MC SWR SBR
76U694-1199
51U590-2033
5.5
3.25
525245 AA2015
71.15 MC 4-SWR SBR With 1 Stop Seal
76U694-1199
51U590-2033,
5.5
3.25
525347 AA20664 107.99 MC 4-SWR SBR Without Stop Seal
76U694-1199
51U2034-2831,
5.5
3.25
525245 AA2015
71.15 MC 4-SWR SBR With 1 Stop Seal
76U1200-2728
51U2034-2831,
5.5
3.25
525347 AA20664 107.99 MC 4-SWR SBR Without Stop Seal
76U1200-2728
51U2832-Up,
5.5
3.25
525347 AA20664 107.99 MC 4-SWR SBR
76U2729-Up, 61X
51U2832-Up,
5.5
3.25
669347 AA2741 110.48 MC SWR SBRB
61X381-Up
Bucket
51U1-589,
5.5
3.25
525222 AA2005
66.64 MC SWR SBR Use w/ C 8J1691 piston
76U1-693
51U1-589
5.5
3.25
525247 AA2020
73.78 MC 4-SWR SBR
51U590-2033
5.5
3.25
525222 AA2005
66.64 MC SWR SBR Use w/ C 8J1691 piston
51U590-2033
5.5
3.25
525247 AA2020
73.78 MC 4-SWR SBR Use w/ C 3G2994 piston
51U590-2033,
5.5
3.25
525248 AA2025
83.97 MC 4-SWR SBR Use w/ C 3G3261 piston
76U1200-2728
With 2 Stop Seals
51U590-2033,
5.5
3.25
525343 AA2066
95.77 MC 4-SWR SBR With 1 Stop Seal
76U1200-2728
51U2034-2831
5.5
3.25
525248 AA2025
83.97 MC 4-SWR SBR With 2 Stop Seals
51U2034-2831,
5.5
3.25
525343 AA2066
95.77 MC 4-SWR SBR With 1 Stop Seal
76U2729-3764, 61X1-380
51U2832-Up,
5.5
3.25
525343 AA2066
95.77 MC 4-SWR SBR With 1 Stop Seal
76U3765-Up, 61X381-Up
51U2832-Up,
5.5
3.25
525347 AA20664 107.99 MC 4-SWR SBR Without Stop Seal
76U3765-Up, 61X381-Up
51U2832-Up,
5.5
3.25
669347 AA2741 110.48 MC SWR SBRB
61X381-Up
Stick
51U1-589
6.0
3.75
561220 AA2495 160.79 MC SWR SBR
76U1-693
20S, 51U1-589
6.0
3.75
561225 AA2500 105.49 MC 4-SWR SBR Change 0
76U1-693
51U1-589
6.0
3.75
561246 AA2505 135.30 MC 4-SWR SBR Change 1
51U590-2033
6.0
3.75
561220 AA2495 160.79 MC SWR SBR
51U590-2033,
6.0
3.75
561225 AA2500 105.49 MC 4-SWR SBR Change 0
76U694-1199
51U590-2033
6.0
3.75
561246 AA2505 135.30 MC 4-SWR SBR Change 1
76U694-1199
51U590-2033,
6.0
3.75
561346 AA2517 112.92 MC 4-SWR SBR Change 2 & 3
76U694-1199
51U2034-2831
6.0
3.75
561246 AA2505 135.30 MC 4-SWR SBR With 2 Stop Seals
76U1200-2728
51U2034-2831,
6.0
3.75
561346 AA2517 112.92 MC 4-SWR SBR With 1 Stop Seal
76U1200-2728
51U2832-Up,
6.0
3.75
561346 AA2517 112.92 MC 4-SWR SBR
76U2729-Up
51U2832-Up,
6.0
3.75
638346 AA2712 164.89 MC SWR SBRB
76U3765-Up
61X1-380-Up
6.0
3.75
561346 AA2517 112.92 MC 4-SWR SBR
61X381-Up
6.0
3.75
638346 AA2712 164.89 MC SWR SBRB
Clamshell
8.25 3.5
529224 AA2155 139.92 MC 4-SWR SBR
Track
20S, 51U, 76U
3.5
1.875
903400 AA28426
22.28 VS SWR SBR
Adjuster
51U2832-Up,
5.5
3.0
901405 AA2841
38.78 VS SWR SBR Use w/ C 8K2623 Front Idler Group
76U3765-Up
We do not imply that any part listed is the product of these manufacturers.
All descriptions and numbers are used for reference purposes only
Prices subject to change without notice
225 EXCAVATOR
EXCAVATOR Serial #s: 20S1-Up, 51U1-Up, 61X1-Up (Pedestal Mounted), 76U1-Up
CAT. 225
215,215B EXCAVATOR
EXCAVATOR #s: 96L1-Up, 14Z1-Up, 3LC1-Up, 61Z1-Up, 2XC1-Up, 9YB1-Up
CAT. 215,B
215C, 215D, 219, 219D EXCAVATOR
EXCAVATOR #s: 5CF1-Up, 9TF1-Up, 4HG1-Up, 5XG1-Up
CAT. 215C,D, 219,D
